XD5-12KTR Three-phase Hybrid Inverter
XD5-12KTR Three-phase Hybrid Inverter - 图片 2
XD5-12KTR Three-phase Hybrid Inverter - 图片 3
XD5-12KTR Three-phase Hybrid Inverter - 图片 4
,

XD5-12KTR Three-phase Hybrid Inverter

XD5-12KTR is the latest three-phase energy storage inverter designed for households and small commercial solar power plants. It has built-in self-generation and self-consumption, peak shaving and valley filling, battery priority, backup power, and other operating modes. Additionally, it also boasts a range of energy storage solutions, including multiple units in parallel, three-phase unbalanced output, Anti-reflux, etc. With its comprehensive feature set, the XD5-12KTR is an ideal choice for those seeking a reliable and efficient hybrid inverter for their solar power plant.

分类： , 标签：
ENQUIRY!
  • Efficient & Higher revenue
  • 160% DC input oversizing, Max. PV input current 20A
  • Max. charge/discharge current 50A
  • 110% output power oversizing, 200% peak output power
  • Intelligent, Simple O&M
  • Smart I-V Curve Diagnosis Function: locate PV string faults accurately and automatically detect faults
  • IP66 protection: support outdoor installation
  • DC & AC type II SPD: prevent lightning damage
  • Flexible & Abundant configuration
  • Plug & play, EPS switching under 10ms
  • AFCI function (optional): when an arc-fault is detected the inverter immediately stops operation
  • Multiple working modes
